Processing Sequence
sequenceDiagram
actor User
participant DesktopApp
participant Loader
participant Chunker
participant OllamaProvider
participant Verifier
participant Categorizer
participant ProductionMap
User->>DesktopApp: Choose design text and start generation
DesktopApp->>Loader: Load and normalize source text
Loader-->>DesktopApp: Clean document text
DesktopApp->>Chunker: Split document into chunks
Chunker-->>DesktopApp: Chunk list
loop For each chunk
DesktopApp->>OllamaProvider: Summarize chunk with local model
OllamaProvider-->>DesktopApp: Generated summary
DesktopApp->>Verifier: Validate summary
Verifier-->>DesktopApp: Accept or fallback
DesktopApp->>Categorizer: Classify useful content
Categorizer-->>DesktopApp: Production category
end
DesktopApp->>ProductionMap: Assemble categorized notes
ProductionMap-->>User: Markdown production map
Shows the core user-to-output workflow without exposing private prompt details.
Strategy Pattern Class View
classDiagram
class Categorizer
Categorizer : -strategies
Categorizer : +categorize(text)
class CategoryStrategy
CategoryStrategy : +score(text)
CategoryStrategy : +categoryName
class CharacterStrategy
class MechanicsStrategy
class WorldLevelStrategy
class StoryStrategy
class UIStrategy
class SystemsStrategy
class UncategorizedStrategy
Categorizer --> CategoryStrategy
CategoryStrategy <|.. CharacterStrategy
CategoryStrategy <|.. MechanicsStrategy
CategoryStrategy <|.. WorldLevelStrategy
CategoryStrategy <|.. StoryStrategy
CategoryStrategy <|.. UIStrategy
CategoryStrategy <|.. SystemsStrategy
CategoryStrategy <|.. UncategorizedStrategy
Shows how category logic can expand without rewriting the main categorizer.
Chunk Lifecycle
stateDiagram-v2
[*] --> Loaded
Loaded --> Chunked
Chunked --> SubmittedToModel
SubmittedToModel --> Verified
SubmittedToModel --> FallbackNeeded
FallbackNeeded --> Verified
Verified --> Categorized
Categorized --> AddedToProductionMap
AddedToProductionMap --> [*]
Shows how a raw text chunk becomes useful production-map material.
Production Map Assembly
flowchart TD
A[Design Document] --> B[Load Text]
B --> C[Chunk Content]
C --> D[Summarize Locally]
D --> E{Response Valid?}
E -->|Yes| F[Categorize]
E -->|No| G[Fallback Summary]
G --> F
F --> H[Group By Production Category]
H --> I[Write Markdown Production Map]
I --> J[Reviewable Planning Artifact]
Shows the product-level transformation from raw design text to an organized planning artifact.
